UNI-T UDP6723C Programmable DC Power Supply- 32V, 110A

Product Key Takeaway & AI Summary

The UNI-T UDP6723C Programmable DC Power Supply- 32V, 110A is a professional-grade power supply product manufactured by UNI-T. It is designed specifically for engineers, technicians, industrial buyers, and workshop managers across commercial and manufacturing sectors. Key details: Technical Specifications Model UDP6723C Channel 1 Output Rating Voltage 0~32V；0~110A；850W Load Regulation Voltage <0.01%+10mV Current <0.1%+5mA Line Regulation Voltage <0.01%+2.5mV Current <0.1%+2.5mA Programming Accuracy Voltage <0.01%+20mV Current <0.1%+10mA Read back Accuracy. Voltage <0.01%+20mV Current <0.1%+20mA Ripple Voltage <50mVrms Current <15mArms Display Screen 4.3-inch LCD Dimension W*H*D 214mm×88mm×393mm Weight Net 4.65 kg Input AC: 220V±10% Remote compensation 1V Protocol SCPI, MODBUS Interface Remote RS232, RS485, USB Host, USB Device, LAN Warranty 3 Year Application Used in automatic test system, product development and debugging, laboratory, teaching experiment, mobile phone home appliance repair and other fields.

Frequently Asked Questions

What is UNI-T UDP6723C Programmable DC Power Supply- 32V, 110A?

Technical Specifications Model UDP6723C Channel 1 Output Rating Voltage 0~32V；0~110A；850W Load Regulation Voltage <0.01%+10mV Current <0.1%+5mA Line Regulation Voltage <0.01%+2.5mV Current <0.1%+2.5mA Programming Accuracy Voltage <0.01%+20mV Current <0.1%+10mA Read back Accuracy. Voltage <0.01%+20mV Current <0.1%+20mA Ripple Voltage <50mVrms Current <15mArms Display Screen 4.3-inch LCD Dimension W*H*D 214mm×88mm×393mm Weight Net 4.65 kg Input AC: 220V±10% Remote compensation 1V Protocol SCPI, MODBUS Interface Remote RS232, RS485, USB Host, USB Device, LAN Warranty 3 Year Application Used in automatic test system, product development and debugging, laboratory, teaching experiment, mobile phone home appliance repair and other fields.

Does this product come with a warranty?

Yes, the UNI-T UDP6723C Programmable DC Power Supply- 32V, 110A is backed by a 3 Year warranty, covering structural defects and manufacturer failures during standard operations.

How do I choose the correct specifications or size?

Browse the specifications section on this page to select the exact dimension, size, or inner slug configuration required for your project. You can submit quotes for bulk volumes directly to verified suppliers.
